Zeb HDXVR 5016
Features
| 16 Channel XVR Recorder | |
| Records with H.265 and H.264 Decoding Formats | |
| Supports Cameras up to 5 Megapixels | |
| ONVIF | |
| Smartphone P2P Connectivity | |
| SATA Storage Supporting up to 8TB | |
| Supports Simultaneous Real-Time Viewing on up to 25 Channels | |
| Video Output up to 1080P Resolution | |
| Compatible with CMS (Central Management Software) |
Specifications
| Operating System | Embedded LINUX | |
| Video Input | 16 Channel Analog + 2 Channel IP | 18 Channel IP | |
| Total Bandwidth | Incoming 16 Mbps (max. 80)/ | |
| Video Output | 1 x HDMI, 1 x VGA , 1 x BNC | |
| Audio Input | IP camera audio / Analog camera audio + RCA audio Input | |
| Audio Output | Support HDMI audio output, audio output (RCA ) | |
| External Ports |
RJ45 - 10/100 port x 1 |
|
| Display Resolution | 1920×1080,1280×1024,1024×768 , CVBS | |
| Display Split | Support multi-screen split; 1/4 screen real-time preview | |
| Privacy Masking | Yes | |
| Video Compression | H.264/H.265 decoding format | |
| Recording Resolution |
8MP Lite / 5MP Lite / 4MP Lite / 1080P / 1080P Lite / 720P / WD1 | |
| Record Mode |
Timing, Manual,Motion Detection & AI Recording | |
| Storage | 1 x SATA Storage devices with upto 10TB compatibility | |
| Network Protocols |
TCP/IP, HTTP, HTTPS, 802.1x, DHCP, DDNS,RTP,RTSP,RTCP, NTP, UPnP, SMTP,Ipv6, UDP,WebSocket, PPPoE, SNMP,IGMP | |
| CMS software Compatibility |
Yes | |
| Win 10 and higher compatibility |
Yes | |
| Multiple browser compatibility |
Yes | |
| Motion Detection notification |
Yes | |
| Alerts via p2p connected devices | Yes | |
| Smart Phone Compatibility |
Yes | |
| Power Input | DC 12V, 3A (External Adapter) | |
| Working Temperature |
-10°C to 50°C | |
| Body Type |
Metal | |
| Physical Parameter | ||
| Product Dimension W x D x H |
25.5 x 22.4 x 4.2 cm | |
| Package Dimension W x D x H: | 34.5 x 7.7 x 27.8 cm | |
| Net. Weight | 679 g | |
| Package Contents | ||
| Recorder |
1U |
|
| Power Adapter |
1U | |
| Mouse | 1U | |
| Hard Disk Mounting Kit | 1U | |
| QR Code User Guide | 1U |
$239.30
Zeb HDXVR 5016—
$239.30
