Zeb IPPDSL5
Features
| ICR / AGC / BLC / AWB | |
| DNR / DWDR / HLC | |
| 2 Warm Light LED | |
| 5 MP | |
| 20M Range (Max) | |
| Night vision with Color |
Specifications
| Camera | ||
| Image processor |
1/2.7" CMOS sensor | |
| Minimum illumination |
0.03 [email protected] (Color, 30 IRE) 0.003 [email protected] (B/W, 30 IRE) 0 Lux (IR on) |
|
| Image Sensor |
1/2.9" CMOS sensor | |
| Shutter speed |
1/50 (1/60) to 1/100,000 seconds | |
| Angle of view | 3.6mm: Horizontal: 92°; Vertical: 48°; Diagonal: 109° | |
| Scanning system |
Progressive Scan | |
| Lens | ||
| Focus Length |
3.6 mm (Fixed) | |
| Mount Type / Lens | M12 | |
| Focus Control | Fixed | |
| Lens Type | Removable | |
| Auto Iris |
Support |
|
| Lens | 3.6mm | |
| Max. Aperture | F2,0 | |
| Night Vision | ||
| IR Cut filter | Yes | |
| IR Range | 20-25M |
|
| IR Power On | Auto Control | |
|
Camera Features |
||
| OSD Support | No | |
| No of IR LEDs | 2 Array IR LED | |
| Day/Night | Support | |
| Picture Adjustment | Yes | |
| WDR | Yes | |
| White Balance | Automatic | |
| AGC (Gain Control) | Auto / Manual | |
| ICR (Infrared Cut Removable Filter) | Auto(ICR)/Color/B/W | |
| Back Light Compensation | BLC / HLC / DWDR | |
| Video output |
||
| Main stream |
2880 × 1620 (1 fps–20 fps) 2688 × 1520(1 fps–25/30 fps) |
|
| Sub stream | 704 × 576 (1 fps–25 fps) 704 × 480 (1 fps–30 fps) |
|
| *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. | ||
| Video Compression | H.265 | |
| Weatherproof Standard | No | |
| S/N Ratio | >120dB | |
| Reset | Yes | |
| General | ||
| Power Consumption | DC12V±10%, 500mA to 1A / 7.5W to 10W POE | |
| Operating Temperature |
10°C ~ +60°C/ Less than 95%RH | |
| Weight | 210 g | |
| Body type | ABS Plastic | |
| Dimension (Dia x H) | 10.5 x 8.7 in cm | |
| Country of Origin | India | |
| Package Contents | ||
| CCTV Camera | 1 U | |
| Mounting Kit | 1 U | |
| QR Code User Manual | 1 U | |
| IP Cable Cap | 1 U |
$16.23
Original: $54.10
-70%Zeb IPPDSL5—
$54.10
$16.23Product Information
